Greenlee DM-210A-C Digital Multimeter with Calibration, Cap, Temp

Description

General InformationBrandGreenleePart NumberDM-210A-CProduct TypeDigital MultimeterWhat’s Included(2) 1.5V AAA Batteries, Bead Temperature Probe (DM-210A, DM-510A Only, 400 DEG F/204 DEG C max), Test leads, ProtectiveBootPackagingRetailCountry of OriginTaiwanUPC783310357575California ResidentsProposition 65 WarningPhysical CharacteristicsWeight0.61 kg1.35 lbDetailsMeasurement StandardCAT IV, CAT III, CAT II, C/ULUS Listed, CE ListedFeaturesMeasures voltage, current, resistance and frequency
Tests continuity and diodes
Backlit LCD with 6,000 count display
Two voltage detection modes – non-contact or using a single test lead
BeepJack warns when test leads are incorrectly inserted in current measurement terminals
Automatic and manual range selection
Relative offset mode to see changes in measurements
Data hold
Use optional USB / RS-232 interface DMSC-2U for direct-to-PC logging
Lifetime Limited Warranty
Accessories included: (2)1.5V AAA batteries, bead temperature probe (DM-210A, DM-510A only, 400F/204C max), test leads, protective boot
Measures capacitance
Measures temperature using a type K thermocouple
Includes Certificate of Calibration

Amperage Measurement: 600, 6000A; 60, 600 mA; 6, 8A
Measurement Category: CAT IV 300 V, CAT III 600 V, CAT II 1000 VVoltage60, 600 mV; 6, 60, 600, 1000VCapacitance60, 600 nF; 6, 60, 600, 3000FResistance (Ohms)600 ; 6, 60, 600 k; 6, 60 MFrequency10Hz – 50kHz Sine Wave, 5Hz – 999.9kHz Logic Level Square WaveBatteries(2) 1.5 V AAADisplay TypeBacklit LCD With 6,000 CountTemperature RangeK Type, -58 To 1832F (-50 To 1000C)
